Hameg HMO3052
Mixed signal oscilloscope, 500 MHz, 2 channels, 4 GSa/s, 8 Mpts (HMO3000 Series)
500 MHz Bandwidth
2 analog + up to 16 logic (MSO) Number of Channels
4 GSa/s (2 GSa/s per channel) Sample Rate
8 Mpoints (4 Mpoints per channel) Memory Depth
8-bit Vertical Resolution
| Attribute | Value |
|---|---|
| Bandwidth | 500 MHz |
| Number of Channels | 2 analog + up to 16 logic (MSO) |
| Sample Rate | 4 GSa/s (2 GSa/s per channel) |
| Memory Depth | 8 Mpoints (4 Mpoints per channel) |
| Vertical Resolution | 8-bit |
| Digital Channels | Up to 16 logic channels with HO3516 probe |
| Vertical Sensitivity | 1 mV/div to 5 V/div |
| Input Impedance | 1 MΩ / 50 Ω switchable |
| Zoom | Up to 200,000:1 |
| Waveform Update Rate | Up to 200,000 waveforms/s with segmented memory option HOO14 |
| Other Functions | 4-bit pattern generator, FFT, automatic measurements |
| Display | 6.5-inch VGA (640 x 480) colour TFT |
| Connectivity | USB stick; dual interface USB/RS-232 (HO720), optional Ethernet/USB (HO730) or GPIB (HO740) |
| Series | Rohde & Schwarz (Hameg) HMO3000 |
Hameg HMO3052 Mixed Signal Oscilloscope Options:
- HMO3052 - HOO10 - Analysis of I²C, SPI and UART/RS-232 signals on analog and logic channels
- HMO3052 - HOO11 - Analysis of I²C, SPI and UART/RS-232 signals on all analog channels
- HMO3052 - HOO12 - Analysis of CAN and LIN signals on analog and logic channels
- HMO3052 - HOO14 - Segmented Memory option (divide acquisition memory into up to 1000 segments, 200,000 Wfm/s)
- HMO3052 - HV452 - Bandwidth upgrade from 400MHz to 500MHz (2 channel)
- HMO3052 - HV352 - Bandwidth upgrade from 300MHz to 500MHz (2 channel)
- HMO3052 - HV114 - Upgrade voucher for Segmented Memory option HOO14
The HMO3052 500 MHz 2 channel oscilloscope offers excellent performance at an attractive price. The standard MSO functionality allows you to analyse along all channels plus up to an additional 16 digital channels. Offers hardware-accelerated signal triggering and decoding for all protcols.
Key Features
- 4 Gsample/s realtime sampling rate, low-noise flash A/D converter
- 8 Mpoint memory, zoom up to 200 000:1
- Automatically or manually adjustable memory depth
- Segmented memory option (HOO14)
- MSO functionality included as standard (HO3508/HO3516 logic probe with 8/16 logic channels required)
- Vertical sensitivity down to 1 mV/div
- Trigger modes: slope (A/B), pulse width, video, logic, serial buses (optional), hold-off
