Keithley 2260B-250-4
| Attribute | Value |
|---|---|
| Output Voltage | 0 – 250 V |
| Output Current | 0 – 4 A |
| Output Power | 1000 W |
| Line Regulation (Voltage) | ≤0.01% + 10 mV |
| Load Regulation (Voltage) | ≤0.01% + 10 mV |
| Voltage Programming Accuracy | ±(0.05% + 100 mV) |
| Current Programming Accuracy | ±(0.2% + 20 mA) |
| Interface | USB, LAN (LXI), GPIB (optional), RS-232 |
| Operating Temperature | 0°C to 50°C |
| Form Factor | 2U Half-Rack |
Keithley 2260B-250-4 Options:
- 2260B-250-4 - EW - 3-year factory warranty extended to 1 additional year from date of shipment
- 2260B-250-4 - 5Y-EW - 3-year factory warranty extended to 5 years from date of shipment
- 2260B-250-4 - 3Y-STD - KeithleyCare 3 Year Standard Calibration Plan
- 2260B-250-4 - 3Y-DAT - KeithleyCare 3 Year Calibration with Data Plan
- 2260B-250-4 - 5Y-STD - KeithleyCare 5 Year Standard Calibration Plan
- 2260B-250-4 - 5Y-DAT - KeithleyCare 5 Year Calibration with Data Plan
- 2260B-250-4 - GPIB-USB - GPIB-to-USB Adapter
- 2260B-250-4 - EXTERM - Extended Terminal (Test Leads, 0.7m, and terminal box)
- 2260B-250-4 - RMK-JIS - Rack Mount Kit (JIS racks)
- 2260B-250-4 - RMK-EIA - Rack Mount Kit (EIA racks)
| Model | 2260B-250-4 |
|---|
The Keithley 2260B-250-4 power supply features programmable voltage and current slew rates from 0.1V/s to 60V/s, internal resistance up to 55.55Ω, and precise rise/fall time control to simulate realistic power conditions. Designed for test automation, it offers USB, LAN, analog, and optional GPIB interfaces.
Applications include LED testing, automotive systems, battery research, and life testing under varying power profiles with customizable voltage waveforms and analog controls.
Testwall can supply the used Keithley 2260B-250-4, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keithley 2260B-250-4.
