Keithley 2260B-30-108
| Attribute | Value |
|---|---|
| Output Voltage | 0 – 30 V |
| Output Current | 0 – 108 A |
| Output Power | 3240 W |
| Line Regulation (Voltage) | 0.01% + 10 mV |
| Load Regulation (Voltage) | 0.01% + 10 mV |
| Ripple and Noise (Voltage, rms) | 15 mV rms |
| Programming Interfaces | USB, RS-232, GPIB, Analog |
| AC Input Voltage | 208 V / 240 V AC, Single Phase |
| Form Factor | 2U Rack Mount |
| Operating Temperature | 0°C to 50°C |
Keithley 2260B-30-108 Options:
- 2260B-30-108 - EW - 3-year factory warranty extended to 1 additional year from date of shipment
- 2260B-30-108 - 5Y-EW - 3-year factory warranty extended to 5 years from date of shipment
- 2260B-30-108 - 3Y-STD - KeithleyCare 3 Year Standard Calibration Plan
- 2260B-30-108 - 3Y-DAT - KeithleyCare 3 Year Calibration with Data Plan
- 2260B-30-108 - 5Y-STD - KeithleyCare 5 Year Standard Calibration Plan
- 2260B-30-108 - 5Y-DAT - KeithleyCare 5 Year Calibration with Data Plan
- 2260B-30-108 - GPIB-USB - GPIB-to-USB Adapter
- 2260B-30-108 - EXTERM - Extended Terminal
- 2260B-30-108 - RMK-JIS - Rack Mount Kit (JIS racks)
- 2260B-30-108 - RMK-EIA - Rack Mount Kit (EIA racks)
| Model | 2260B-30-108 |
|---|
The Keithley 2260B-30-108 power supply delivers precise programmable control of voltage and current rise/fall times, minimizing inrush currents and overshoot spikes. Voltage slew rates range from 0.1V/s to 60V/s, while current priority mode ensures smooth power delivery with fall time programmability. An internal resistance of up to 0.278Ω simulates battery behaviors across chemistries, enhancing real-world circuit testing.
Equipped with USB, LAN, optional GPIB, and analog input control, the 2260B-30-108 supports custom voltage profiles and waveform generation. It suits LED, automotive, battery, and stress testing, with 0–30 V output, 1080W power, and up to 108A current.
Testwall can supply the used Keithley 2260B-30-108, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keithley 2260B-30-108.
