Keithley 2260B-80-40
| Attribute | Value |
|---|---|
| Output Voltage | 0 – 80 V |
| Output Current | 0 – 40 A |
| Output Power | 1080 W |
| Line Regulation (Voltage) | ≤0.01% + 10 mV |
| Load Regulation (Voltage) | ≤0.01% + 10 mV |
| Ripple and Noise (Voltage, RMS) | ≤15 mV |
| Programming Interface | USB, RS-232, GPIB, LAN (LXI) |
| Voltage Setting Resolution | 10 mV |
| Current Setting Resolution | 10 mA |
| AC Input Voltage | 100/120/220/240 VAC, 47–63 Hz |
Keithley 2260B-80-40 Options:
- 2260B-80-40 - 2260-001 - Accessory Kit: Analog control mating connector, pins, cover, and ground wire
- 2260B-80-40 - 2260-002 - Simple IDC Tool
- 2260B-80-40 - 2260-003 - Contact Removal Tool
- 2260B-80-40 - 2260-004 - Basic Accessories Kit: Air filter, analog connector cover, analog control lock lever, M8-size output terminal bolts, washers and screws, and M4-size output terminal screws with washers
- 2260B-80-40 - 2260-005 - Cable, 0.5m (1.6 ft.), to connect two Series 2260B power supplies in series
- 2260B-80-40 - 2260-006 - Cable, 0.5m (1.6 ft.), to connect two Series 2260B power supplies in parallel
- 2260B-80-40 - 2260B-007 - Cable, 0.5m (1.6 ft.), to connect three Series 2260B power supplies in parallel
- 2260B-80-40 - 2260B-GPIB-USB - GPIB-to-USB Adapter: Provides a GPIB interface for the Series 2260B power supplies
- 2260B-80-40 - 2260B-EXTERM - Extended Terminal: Test Leads, 0.7m (28 in.), and terminal box to bring outputs to the front of the instrument or another location. Magnetic base attaches to side of instrument
- 2260B-80-40 - 2260B-RMK-EIA - Rack Mount Kit (EIA racks)
- 2260B-80-40 - 2260B-RMK-JIS - Rack Mount Kit (JIS racks)
- 2260B-80-40 - EW - 3-year factory warranty extended to 1 additional year from date of shipment
- 2260B-80-40 - 5Y-EW - 3-year factory warranty extended to 5 years from date of shipment
- 2260B-80-40 - C/2260B-80-40-3Y-STD - KeithleyCare 3 Year Standard Calibration Plan
- 2260B-80-40 - C/2260B-80-40-3Y-DAT - KeithleyCare 3 Year Calibration with Data Plan
- 2260B-80-40 - C/2260B-80-40-5Y-STD - KeithleyCare 5 Year Standard Calibration Plan
- 2260B-80-40 - C/2260B-80-40-5Y-DAT - KeithleyCare 5 Year Calibration with Data Plan
| Model | 2260B-80-40 |
|---|
The Keithley 2260B-80-40 is a programmable DC power supply with precise control of voltage/current rise and fall times, emulating battery characteristics with up to 1.975Ω internal resistance. It delivers up to 80V and 40.5A with 1080W power output, supports analog, USB, LAN, and optional GPIB interfaces, and features fast discharge and 1ms transient recovery time, ideal for automated test systems.
Used in automotive, LED, and high-power component testing, it allows simulation of dynamic load conditions with customizable output waveforms and sequences for accurate DUT evaluation.
Testwall can supply the used Keithley 2260B-80-40, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keithley 2260B-80-40.
