Keithley 2260B-800-1
| Attribute | Value |
|---|---|
| Output Voltage | 0 – 800 V |
| Output Current | 0 – 1.44 A |
| Output Power | 1152 W |
| Line Regulation (Voltage) | ≤ 0.01% + 10 mV |
| Load Regulation (Voltage) | ≤ 0.01% + 10 mV |
| Voltage Programming Accuracy | ≤ 0.05% + 500 mV |
| Current Programming Accuracy | ≤ 0.1% + 3.6 mA |
| Interface | USB, GPIB, RS-232, Analog |
| AC Input Voltage | 100 – 240 VAC, 50/60 Hz |
| Form Factor | 2U Half-Rack |
Keithley 2260B-800-1 Options:
- 2260B-800-1 - EW - 3-year factory warranty extended to 1 additional year from date of shipment
- 2260B-800-1 - 5Y-EW - 3-year factory warranty extended to 5 years from date of shipment
- 2260B-800-1 - 3Y-STD - KeithleyCare 3 Year Standard Calibration Plan
- 2260B-800-1 - 3Y-DAT - KeithleyCare 3 Year Calibration with Data Plan
- 2260B-800-1 - 5Y-STD - KeithleyCare 5 Year Standard Calibration Plan
- 2260B-800-1 - 5Y-DAT - KeithleyCare 5 Year Calibration with Data Plan
- 2260B-800-1 - GPIB-USB - GPIB-to-USB Adapter
- 2260B-800-1 - EXTERM - Extended Terminal; Test Leads, 0.7m (28 in.), and terminal box to bring outputs to the front of the instrument or another location
- 2260B-800-1 - RMK-JIS - Rack Mount Kit (JIS racks)
- 2260B-800-1 - RMK-EIA - Rack Mount Kit (EIA racks)
| Model | 2260B-800-1 |
|---|
The Keithley 2260B-800-1 power supply offers precise programmable rise and fall times for both voltage and current to prevent inrush current damage. Voltage slew rate ranges from 0.1V/s to 1600V/s and current priority mode ensures accurate current delivery. Simulates a variety of battery chemistries using programmable internal resistance up to 277.8Ω and features 1ms transient recovery and fast discharge capability for efficient test conditions.
It supports analog, USB, LAN, and optional GPIB interfaces, enabling integration into automated systems. Use internal sequences to test DUT at varied voltage levels or simulate AC on DC power to assess circuit resilience.
Testwall can supply the used Keithley 2260B-800-1, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keithley 2260B-800-1.
