Keithley
Keithley 2601B
Single-Channel System SourceMeter, 40V, 10A Pulse
SourceMeter (SMU) Instrument type
1 Number of channels
±40 V Maximum voltage (source/measure)
±3 A Maximum current (DC)
±10 A Maximum current (pulse)
| Attribute | Value |
|---|---|
| Instrument type | SourceMeter (SMU) |
| Number of channels | 1 |
| Maximum voltage (source/measure) | ±40 V |
| Maximum current (DC) | ±3 A |
| Maximum current (pulse) | ±10 A |
| Maximum power (DC) | 40.4 W |
| Minimum current resolution | 100 fA |
| Minimum voltage resolution | 1 µV |
| Measurement resolution | 6½ digits |
| Interfaces | GPIB, USB, LAN (LXI), RS-232, Digital I/O, TSP-Link |
| Programming | TSP (Lua) |
The Keithley 2601B is a single-channel System SourceMeter rated to 40 V, 3 A DC and 10 A pulsed. It integrates a precision power supply, true current source, DMM, arbitrary waveform and pulse generator and electronic load, with Test Script Processor (TSP) technology for fast embedded test scripts. TSP-Link allows multiple units to be combined into a high-channel-count system for production and research I-V testing.
Testwall can supply the used Keithley 2601B fully tested, with calibration available on request and delivery across Europe. Send us your requirements and ask for a quote.
