Keithley
Keithley 8011
High Current Test Socket Kit
Keithley 196, 199 Digital Multimeters Compatible Instrument
Test Fixture / Terminal Board for High Resistance Measurements Function
High Resistance, Resistivity, and Insulation Resistance Measurement Type
Includes guarded terminal connections to minimize leakage currents Guard Terminal
Triax and banana jack connectors for low-noise signal connections Input Connectors
| Attribute | Value |
|---|---|
| Compatible Instrument | Keithley 196, 199 Digital Multimeters |
| Function | Test Fixture / Terminal Board for High Resistance Measurements |
| Measurement Type | High Resistance, Resistivity, and Insulation Resistance |
| Guard Terminal | Includes guarded terminal connections to minimize leakage currents |
| Input Connectors | Triax and banana jack connectors for low-noise signal connections |
| Shielding | Shielded enclosure to reduce electromagnetic interference (EMI) |
| Maximum Voltage | 1000V DC |
| Insulation Resistance | High insulation resistance between terminals to ensure measurement accuracy |
| Construction | Durable metal enclosure with low-leakage insulating materials |
| Application | Laboratory and production testing of high-impedance components and materials |
| Model | 8011 |
|---|
The Keithley 8011 Test Fixture is engineered for seamless integration with Series 8000 parametric test systems, supporting 20- and 40-lead DIP ICs. With reduced signal path length, it ensures superior measurement fidelity for precise device characterization.
Its spring-loaded contacts provide reliable DUT connections, ideal for low-level signal and high-precision testing, with fast DUT swapping for high throughput environments.
Testwall can supply the used Keithley 8011, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keithley 8011.
