Keysight (Agilent) 11850C
| Attribute | Value |
|---|---|
| Frequency Range | DC to 18 GHz |
| Connector Type | Type-N (50 Ohm) |
| Number of Ports | 4-Way Power Divider/Combiner |
| Impedance | 50 Ohm |
| Insertion Loss | Typically 7 dB (splitting loss) plus excess loss |
| VSWR | Less than 1.5:1 typical |
| Isolation Between Ports | Greater than 20 dB typical |
| Maximum Input Power | 1 Watt (30 dBm) average |
| Operating Temperature | 0°C to +55°C |
| Device Function | RF Power Divider / Splitter for signal distribution and combining applications |
| Model | 11850C |
|---|
The Keysight (Agilent) 11850C is a high-precision 50-ohm three-way power splitter, optimized for seamless integration with the Agilent 8753 network analyzer. It features type-N female connectors and supports a broad frequency range from DC to 3 GHz. The splitter offers exceptional tracking of ±0.3 dB and ±3.5°, with leveling of 20 dB at 3 GHz, and a nominal insertion loss of 9.5 dB + 1 dB/GHz. Input port match is rated at 20 dB up to 1.3 GHz and 10 dB from 1.3 to 3 GHz.
It is ideally complemented by the Agilent 11851B RF cable kit and ensures consistent performance across applications requiring accurate signal division.
Testwall can supply the used Keysight (Agilent) 11850C, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) 11850C.
