Keysight (Agilent)
Keysight (Agilent) DSO6104A 4 Ch 1 GHz Digital Storage Oscilloscope
4 Ch 1 GHz Digital Storage Oscilloscope
1 GHz Bandwidth
4 Number of Channels
4 GSa/s Maximum Sample Rate
8 Mpts (standard), up to 32 Mpts (optional) Memory Depth
8-bit Vertical Resolution
| Attribute | Value |
|---|---|
| Bandwidth | 1 GHz |
| Number of Channels | 4 |
| Maximum Sample Rate | 4 GSa/s |
| Memory Depth | 8 Mpts (standard), up to 32 Mpts (optional) |
| Vertical Resolution | 8-bit |
| Rise Time | 350 ps |
| Display | 8.5-inch SVGA color display (800 x 600 resolution) |
| Timebase Range | 1 ns/div to 50 s/div |
| Vertical Sensitivity Range | 1 mV/div to 5 V/div |
| Trigger Types | Edge, Glitch, Pattern, CAN, LIN, I2C, SPI, UART/RS232, USB |
Keysight (Agilent) DSO6104A 4 Ch 1 GHz Digital Storage Oscilloscope Options:
- DSO6104A - 2MH - Memory upgrade to 2 Mpts per channel (half channel: 4 Mpts)
- DSO6104A - 8MH - Memory upgrade to 8 Mpts per channel (half channel: 16 Mpts)
- DSO6104A - LSS - Low Speed Serial decode (I2C and SPI)
- DSO6104A - AMS - Automotive Serial decode (CAN and LIN)
- DSO6104A - SEC - Secure Environment Mode
- DSO6104A - BAT - Battery Operation
| Model | DSO6104A |
|---|
The Keysight (Agilent) DSO6104A oscilloscope provides 1 GHz bandwidth, 4 channels, 4 GSa/s sampling, and deep memory with up to 8 Mpts, ideal for FPGA and serial signal analysis.
Includes full accessory kit, FPGA debug tools, and LXI compliant connectivity.
Testwall can supply the used Keysight (Agilent) DSO6104A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) DSO6104A.
