Keysight (Agilent) J7205B
| Attribute | Value |
|---|---|
| Frequency Range | 75 GHz to 110 GHz (W-Band) |
| Module Type | Frequency Extension Module |
| Compatible Instrument | Keysight 8510C Vector Network Analyzer |
| Waveguide Band | WR-10 |
| Dynamic Range | Up to 80 dB |
| Output Power | Typically -10 dBm |
| Connector Interface | WR-10 Waveguide Flange |
| Measurement Capability | S-Parameter Measurements (S11, S21, S12, S22) |
| Input Frequency | RF and LO Inputs from 8510C Test Set |
| Operating Temperature | 0°C to 55°C |
| Model | J7205B |
|---|
The Keysight (Agilent) J7205B is a 5-channel multi-channel attenuation control unit covering DC to 18 GHz with precise attenuation from 0 to 121 dB in 1 dB steps. It offers an insertion loss of 2.5 dB below 6 GHz and 5.0 dB above, along with return loss of 14 dB and 10 dB respectively. The unit supports SMA/Type-N connectors.
Ideal for signal path emulation and testing, the J7205B ensures repeatable attenuation control across five independent channels, making it suitable for high-frequency applications.
Testwall can supply the used Keysight (Agilent) J7205B, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) J7205B.
