Keysight (Agilent) N1094B
30/50 GHz Quad Electrical Channel Module
DCA-M Wide-Bandwidth Oscilloscope Instrument Type
Up to 80 GHz (with optical module support) Bandwidth
2 electrical channels Number of Channels
100 ps/div to 2 ns/div Timebase Range
Equivalent-time sampling (ETS) Sampling Mode
| Attribute | Value |
|---|---|
| Instrument Type | DCA-M Wide-Bandwidth Oscilloscope |
| Bandwidth | Up to 80 GHz (with optical module support) |
| Number of Channels | 2 electrical channels |
| Timebase Range | 100 ps/div to 2 ns/div |
| Sampling Mode | Equivalent-time sampling (ETS) |
| Trigger Input | External trigger input, supports clock recovery |
| Data Rate Support | Up to 80 Gbaud signal analysis capability |
| Interface/Connectivity | USB and LAN (LXI compliant) |
| Module Compatibility | Compatible with 86100D DCA-X plug-in modules |
| Form Factor | Compact, mainframe-free remote head design |
| Model | N1094B |
|---|
Keysight (Agilent) N1094B 30/50 GHz Quad Electrical Channel Module Description: 20/33/40/50 GHz bandwidth (20/30 GHz optional) Accurate high data rate analysis with <170 fs jitter 2.4 mm input type compact design USB interface (for connection to DCA-X mainframe or PC Keysight (Agilent) N1094B 30/50 GHz Quad Electrical Channel Module
