Keysight (Agilent) N1265A
| Attribute | Value |
|---|---|
| Maximum Current Output | Up to 200A pulsed current |
| Maximum Voltage Output | Up to 10V |
| Number of Quadrants | 4-quadrant operation |
| Compatible Mainframe | Designed for use with Keysight N1200A series mainframes |
| Application | High-current device characterization for power semiconductors, MOSFETs, IGBTs, and diodes |
| Pulse Width | Minimum pulse width of 100 µs |
| Measurement Functions | Current and voltage sourcing and measurement capability |
| Interface/Connectivity | Compatible with Keysight B1500A Semiconductor Device Analyzer via expansion unit |
| Module Type | High-Current Expander Unit (HCSMU expansion) |
| Operating Temperature | 0°C to 40°C |
| Model | N1265A |
|---|
The Keysight (Agilent) N1265A Ultra High Current Expander Unit (UHCU) supports pulsed breakdown measurements up to 1500 A / 60 V with a peak power of 22.5 kW, or ±500 A / 60 V with 7.5 kW peak power, depending on the SMU configuration. Designed for use with the B1505A parameter analyzer, it requires integration with either the B1514A MCSMU or B1512A HCSMU for optimal performance.
This unit delivers precise, flexible, and user-friendly measurements for characterizing high-power semiconductor devices such as IGBTs and other advanced components.
Testwall can supply the used Keysight (Agilent) N1265A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) N1265A.
