Keysight (Agilent)
Keysight (Agilent) U2001H
USB Power Sensor, 10 MHz to 6 GHz, -50 dBm to +30 dBm
10 MHz to 18 GHz Frequency Range
-60 dBm to +20 dBm Power Range
2.92 mm (K-type) male Connector Type
Up to 200 readings/second (free run mode) Measurement Speed
USB 2.0 Interface
| Attribute | Value |
|---|---|
| Frequency Range | 10 MHz to 18 GHz |
| Power Range | -60 dBm to +20 dBm |
| Connector Type | 2.92 mm (K-type) male |
| Measurement Speed | Up to 200 readings/second (free run mode) |
| Interface | USB 2.0 |
| Operating Temperature | 0°C to 55°C |
| SWR (Maximum) | 1.4 (10 MHz to 18 GHz) |
| Measurement Uncertainty | ±0.30 dB (at 25°C, 50 MHz reference) |
| Power Supply | USB bus powered (no external power supply required) |
| Compatibility | Compatible with Keysight N1918A Power Panel Software and BenchVue |
Keysight (Agilent) U2001H Options:
- U2001H - 1A7 - ISO 17025 calibration with test data
- U2001H - A6J - ANSI Z540 calibration with test data
- U2001H - R-51B-001-5Z - Warranty Assurance Plan - Return to Keysight - 5 years
- U2001H - OB1 - English language Operating and Service Guide
- U2001H - ABD - German language Operating and Service Guide
- U2001H - ABE - Spanish language Operating and Service Guide
- U2001H - ABF - French language Operating and Service Guide
- U2001H - ABJ - Japanese language Operating and Service Guide
- U2001H - ABZ - Italian language Operating and Service Guide
- U2001H - AB2 - Simplified Chinese language Operating and Service Guide
| Model | U2001H |
|---|
Keysight U20001H
The Keysight/Agilent U2001H USB Power Sensor makes setup and measurement fast without the need of a power meter, just plug the USB sensor cable to the PC, you can control the USB power sensor with the FREE Power Panel (N1918A) software.
Features and Specifications for this Agilent U2001H USB Power Sensor include:
- Frequency range of 10 MHz to 6 GHz
- Wide dynamic range (-50 dBm to +30 dBm)
- Internal zeroing while connected to the DUT
- High measurement speed of up to 250readings/second
- Support internal and external trigger measurements
- Display power measurements on a PC without the need of power meter
- Compatible with other Keysight/Agilent instruments
- Internal triggering and trace display capability
