Keysight (Agilent) 16719A
| Attribute | Value |
|---|---|
| Channel Count | 136 Channels |
| Maximum State Speed | 800 MHz |
| Maximum Timing Speed | 4 GHz (half channel, 68 channels) |
| Memory Depth | 128 Msa/channel |
| Module Type | Logic Analyzer Module |
| Compatible Systems | Keysight 16900 Series Logic Analysis Systems |
| Threshold Range | -6V to +6V, adjustable in 10 mV increments |
| Minimum Detectable Pulse Width | 250 ps |
| Setup/Hold Time | ±4.0 ns adjustable in 100 ps increments |
| Number of Pods | 17 Pods (8 channels per pod + clock) |
| Model | 16719A |
|---|
The Keysight (Agilent) 16719A is a high-performance logic analysis module featuring 333 MHz state speed and 2 GHz timing zoom with a 32M deep memory. It includes 68 channels per module and supports fast acquisition with up to 340 channels across modules, ensuring precise digital signal capture and analysis for advanced design validation.
Designed for intensive logic diagnostics, the 16719A’s deep memory and fast sampling rates make it ideal for debugging and capturing complex digital signals around trigger events.
Testwall can supply the used Keysight (Agilent) 16719A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) 16719A.
