Keysight (Agilent) 16750B
| Attribute | Value |
|---|---|
| Channel Count | 68 Channels |
| Maximum State Clock Speed | 400 MHz |
| Maximum Timing Speed | 2 GHz (half channel), 1 GHz (full channel) |
| Memory Depth | 32 Mb per channel |
| Threshold Voltage Range | -6.0 V to +6.0 V, adjustable in 10 mV increments |
| Minimum Detectable Pulse Width | 500 ps |
| Setup/Hold Time | Programmable, 0 to 3.5 ns setup, 0 to 3.5 ns hold |
| Form Factor | Single-slot module compatible with Keysight 16700 series mainframes |
| Operating Temperature | 0°C to 55°C |
| Input Impedance | 100 kΩ, 8 pF |
Keysight Technologies 16750B Options:
- 16750B - 0B3 - Add service manual
- 16750B - 1BP - MIL-STD-45662A calibration with test data
- 16750B - W17 - Convert standard warranty to one-year on-site warranty
| Model | 16750B |
|---|
The Keysight (Agilent) 16750B Logic Analysis Module delivers a state speed of 400 MHz and timing speed of 800 MHz, making it ideal for high-speed digital design validation. It offers 4 M memory depth and features 68 channels per module, ensuring deep capture and accurate analysis.
This module supports integration with 16750A units in multi-module configurations, enabling scalable logic analysis solutions tailored to complex systems and advanced debugging requirements.
Testwall can supply the used Keysight (Agilent) 16750B, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) 16750B.
