Keysight (Agilent) 4261A
| Attribute | Value |
|---|---|
| Measurement Parameters | C, L, R, G, D, Q, |Z|, θ |
| Test Frequencies | 120 Hz, 1 kHz, 10 kHz, 100 kHz |
| Measurement Range | 0.00001 pF to 99999 µF (Capacitance); 0.00001 µH to 99999 H (Inductance) |
| Basic Accuracy | 0.1% |
| Test Signal Level | 0.1 Vrms, 1 Vrms |
| Display | 5-digit LED display |
| Measurement Time | Fast: approximately 100 ms; Slow: approximately 500 ms |
| Interface | HP-IB (GPIB) interface |
| Power Requirements | 100/120/220/240 VAC, 48–66 Hz |
| Operating Temperature | 0°C to 55°C |
| Model | 4261A |
|---|
The Keysight (Agilent) 4261A LCR Meter is a high-precision instrument designed to measure capacitance, inductance, resistance, and dissipation factor automatically. It supports both parallel and series equivalent circuit measurements using a five-terminal connection and offers high accuracy at test frequencies of 120Hz and 1kHz. Results are clearly displayed on dual three-digit LED screens.
Ideal for component testing, the 4261A ensures fast and reliable measurements with minimal user input, streamlining laboratory and production line applications.
Testwall can supply the used Keysight (Agilent) 4261A LCR Meter, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) 4261A LCR Meter.
