Keysight (Agilent) 4268A
1 nF - 1 mF Capacitance Meter
Capacitance (C), Dissipation Factor (D), Impedance (Z), Resistance (R), Conductance (G), Quality Factor (Q) Measurement Parameters
120 Hz / 1 kHz Test Frequency
1 fF to 99.999 mF (Capacitance) Measurement Range
0.1% (Capacitance and Dissipation Factor) Basic Accuracy
0.1 Vrms, 0.25 Vrms, 1 Vrms Test Signal Level
| Attribute | Value |
|---|---|
| Measurement Parameters | Capacitance (C), Dissipation Factor (D), Impedance (Z), Resistance (R), Conductance (G), Quality Factor (Q) |
| Test Frequency | 120 Hz / 1 kHz |
| Measurement Range | 1 fF to 99.999 mF (Capacitance) |
| Basic Accuracy | 0.1% (Capacitance and Dissipation Factor) |
| Test Signal Level | 0.1 Vrms, 0.25 Vrms, 1 Vrms |
| Measurement Speed | Fast: 27 ms, Medium: 67 ms, Slow: 267 ms |
| DC Bias Voltage | 0 V, 1.5 V, 2 V (Internal); Up to 40 V (External) |
| Interface / Connectivity | GPIB (IEEE-488), Handler Interface |
| Power Supply | 100 / 120 / 220 / 240 VAC, 50/60 Hz |
| Operating Temperature | 0°C to 55°C (32°F to 131°F) |
| Model | 4268A |
|---|
The Keysight (Agilent) 4268A Capacitance Meter provides precise high-value MLCC testing with a constant test level up to 70 uF at 1 V rms and 1 kHz, or 600 uF at 120 Hz, supporting IEC 384-10 compliance.
