Keysight (Agilent) 54621A
| Attribute | Value |
|---|---|
| Number of Channels | 2 + 16 Logic Channels |
| Bandwidth | 60 MHz |
| Sample Rate | 200 MSa/s |
| Memory Depth | 2 Mpts per channel |
| Vertical Resolution | 8 bits |
| Vertical Sensitivity | 2 mV/div to 5 V/div |
| Time Base Range | 5 ns/div to 50 s/div |
| Input Impedance | 1 MΩ ± 1% in parallel with 13 pF ± 2 pF |
| Display | 6.5-inch QVGA Monochrome LCD |
| Mixed Signal Oscilloscope (MSO) | Yes – Combines oscilloscope and logic analyzer functionality |
Keysight Technologies 54621A Options:
- 54621A - 003 - Shielding Option for use in severe environments or with sensitive devices under test – shields both ways (in and out): RS-03 Magnetic interface shielding added to CRT, and RE-02 display shield added to CRT to reduce radiated interference
- 54621A - 1CM - Rackmount kit (same as 1186A)
- 54621A - A6J - ANSI/NSCL Z540 calibration with test data (replaces 1BP)
- 54621A - W32 - 3-year, customer-return calibration service
- 54621A - W34 - 3-year, customer-return standard comp cal service
- 54621A - W50 - Additional 2-year warranty (5 year total)
- 54621A - W52 - 5-year, customer-return calibration service
- 54621A - W54 - 5-year, customer-return standard comp cal service
- 54621A - ABA - Manual Option: English
- 54621A - ABJ - Manual Option: Japanese
- 54621A - AB2 - Manual Option: Simplified Chinese
| Model | 54621A |
|---|
The Keysight (Agilent) 54621A 2-Channel Oscilloscope features 60 MHz bandwidth and patented high-definition display, with 4 MB deep memory and 25 million vectors/second. Designed for precision, it supports flexible triggering including I²C, SPI, LIN, CAN, and USB, and offers RS-232, parallel ports, and FFT capabilities.
Ideal for engineers requiring deep memory and clear signal resolution, this oscilloscope ensures high sample rates over long time periods with an affordable entry point for two-channel analysis.
Testwall can supply the used Keysight (Agilent) 54621A Oscilloscope, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) 54621A Oscilloscope.
