Keysight (Agilent)
Keysight (Agilent) 54810A
2 Channel 500MHz 1GS/s Digital Storage Oscilloscope
500 MHz Bandwidth
1 GSa/s Sample Rate
2 Analog Channels Number of Channels
2 Mpts per Channel Memory Depth
8-bit Vertical Resolution
| Attribute | Value |
|---|---|
| Bandwidth | 500 MHz |
| Sample Rate | 1 GSa/s |
| Number of Channels | 2 Analog Channels |
| Memory Depth | 2 Mpts per Channel |
| Vertical Resolution | 8-bit |
| Time Base Range | 1 ns/div to 20 s/div |
| Input Impedance | 1 MΩ or 50 Ω |
| Display | 10.4-inch Color LCD Touchscreen |
| Trigger Types | Edge, Glitch, Pattern, State, Delay, Duration, TV, Violation |
| Interface/Connectivity | GPIB, RS-232, Parallel Printer Port |
Keysight Technologies 54810A Options:
- 54810A - 090 - Delete standard probes (2 1160A probes for the 54810A/20A)
- 54810A - 001 - Additional standard probes (2 1160A probes for the 54810A/15A/20A/25A)
- 54810A - 002 - Add 1 1162A 1:1 passive probe
- 54810A - 003 - Add 1 1163A 10:1 500 Ω, low C passive probe
- 54810A - 008 - Add 1 1153A 200 MHz differential probe
- 54810A - 009 - Add 1 1154A 500 MHz differential probe
- 54810A - 010 - Add 1 1159A 1 GHz differential probe
- 54810A - 015 - Extended (runt) triggering
- 54810A - 100 - Communications Mask Test Kit (includes mask library disk and set of termination adapters)
- 54810A - 200 - VoiceControl option
- 54810A - 1BP - Mil Std 45662A and ANSI/NCSL Z-540 calibration with test data
- 54810A - 1CL - Add 1 Keyboard (E2610A)
- 54810A - 1CM - Add 1 Rackmount kit (E2609A)
- 54810A - UL5 - Add 1 Touchpad pointing device (E2612A)
- 54810A - UL6 - Add 1 Clip-on track ball pointing device (E2611A)
- 54810A - W50 - Five-year, customer-return, repair coverage (additional 2 years)
| Model | 54810A |
|---|
The Keysight (Agilent) 54810A Infiniium Oscilloscope delivers 500 MHz bandwidth and 1 GSa/s simultaneous sampling across two channels, offering the precision and speed required for general-purpose design, analysis, and debugging. Its analog-style front panel paired with a Windows-based GUI ensures intuitive control, while advanced features such as USB test with embedded MATLAB, communications mask testing, and time correlation with 16700 series logic analyzers extend its functionality.
With voice control, web-based remote access, and trigger-activated email alerts, the 54810A combines user-friendly design with powerful signal analysis capabilities.
Testwall can supply the used Keysight (Agilent) 54810A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) 54810A.
