Keysight (Agilent) 54825A
4 Channel 500MHz 2GS/s Digital Storage Oscilloscope
1 GHz Bandwidth
4 Number of Channels
4 GSa/s Sample Rate
32 Mpts per channel Memory Depth
8-bit Vertical Resolution
| Attribute | Value |
|---|---|
| Bandwidth | 1 GHz |
| Number of Channels | 4 |
| Sample Rate | 4 GSa/s |
| Memory Depth | 32 Mpts per channel |
| Vertical Resolution | 8-bit |
| Vertical Sensitivity Range | 1 mV/div to 5 V/div |
| Time Base Range | 500 ps/div to 20 s/div |
| Input Impedance | 50 Ω or 1 MΩ |
| Display | 8.4-inch color LCD |
| Interface | GPIB, RS-232, Parallel (Centronics) |
Keysight Technologies 54825A Options:
- 54825A - 090 - Delete standard probes (4 1160A probes for the 54815A/25A)
- 54825A - 001 - Additional standard probes (2 1160A probes for the 54810A/15A/20A/25A)
- 54825A - 002 - Add 1 1162A 1:1 passive probe
- 54825A - 003 - Add 1 1163A 10:1 500 Ω, low C passive probe
- 54825A - 008 - Add 1 1153A 200 MHz differential probe
- 54825A - 009 - Add 1 1154A 500 MHz differential probe
- 54825A - 010 - Add 1 1159A 1 GHz differential probe
- 54825A - 015 - Extended (runt) triggering
- 54825A - 100 - Communications Mask Test Kit (includes mask library disk and set of termination adapters)
- 54825A - 200 - VoiceControl option
- 54825A - 1BP - Mil Std 45662A and ANSI/NCSL Z-540 calibration with test data
- 54825A - 1CL - Add 1 Keyboard (E2610A)
- 54825A - 1CM - Add 1 Rackmount kit (E2609A)
- 54825A - UL5 - Add 1 Touchpad pointing device (E2612A)
- 54825A - UL6 - Add 1 Clip-on track ball pointing device (E2611A)
- 54825A - W50 - Five-year, customer-return, repair coverage (additional 2 years)
| Model | 54825A |
|---|
The Keysight (Agilent) 54825A Infiniium Oscilloscope delivers four-channel performance with 500 MHz bandwidth and 2 GSa/s sampling rate on all channels simultaneously, enabling high-speed signal capture and detailed waveform analysis. With its analog-style front panel and Windows-based GUI, the 54825A offers user-friendly operation paired with powerful digital tools. Advanced capabilities include USB testing with embedded MATLAB, time correlation with 16700 logic analyzers, and communications mask testing.
This oscilloscope also supports hands-free voice control, browser-based remote access, and trigger-activated email notifications, making it ideal for modern, connected test environments.
Testwall can supply the used Keysight (Agilent) 54825A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) 54825A.
