Keysight (Agilent)
Keysight (Agilent) 6038A
60V 10A DC Power Supply
0 to 60 V Output Voltage Range
0 to 10 A Output Current Range
200 W Maximum Output Power
0.1% + 60 mV Voltage Programming Accuracy
0.2% + 20 mA Current Programming Accuracy
| Attribute | Value |
|---|---|
| Output Voltage Range | 0 to 60 V |
| Output Current Range | 0 to 10 A |
| Maximum Output Power | 200 W |
| Voltage Programming Accuracy | 0.1% + 60 mV |
| Current Programming Accuracy | 0.2% + 20 mA |
| Load Regulation (Voltage) | 2 mV |
| Load Regulation (Current) | 4 mA |
| Interface | GPIB (IEEE-488) |
| Input Voltage | 115/230 VAC, 47-63 Hz |
| Operating Temperature Range | 0°C to 55°C |
Keysight Technologies 6038A Options:
- 6038A - Opt 001 - Front panel has only line switch, line indicator, and OVP adjust
- 6038A - Opt 100 - 87 to 106 Vac, 48 to 63 Hz (power supply output is derated to 75%)
- 6038A - Opt 120 - 104 to 127 Vac, 47 to 63 Hz
- 6038A - Opt 220 - 191 to 233 Vac, 48 to 63 Hz
- 6038A - Opt 240 - 209 to 250 Vac, 48 to 63 Hz
- 6038A - Opt 800 - Rack-mount Kit for Two Half-rack Units Side by Side (Lock link Kit p/n 5061-9694 and 7 in Rack adapter Kit 5063-9215)
- 6038A - Opt 908 - Rack-mount Kit for a Single Half-rack Unit (with blank filler panel); p/n 5062-3960
- 6038A - Opt 0L2 - Extra Standard Documentation Package
- 6038A - Opt 0B3 - Service Manual
- 6038A - Opt 0B0 - No documentation package
- 6038A - Opt J01 - Stabilization for loads up to 10 Henries
| Model | 6038A |
|---|
The Keysight (Agilent) 6038A DC Power Supply delivers 0–60V and 0–10A at 240W, featuring autoranging output with analog/resistance control, built-in measurements, and series or auto-parallel configurations. Programming accuracy is ±0.035% (+40 mV) for voltage and ±0.09% (+10 mA) for current, while ripple remains minimal at 3 mV RMS (voltage) and 5 mA RMS (current). Readback accuracy is ±0.07% (+50 mV) for voltage and ±0.2% (+11 mA) for current.
Its compact design and performance make it ideal for system integration in budget-sensitive, high-demand test environments requiring accuracy and flexibility.
Testwall can supply the used Keysight (Agilent) 6038A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) 6038A.
