Keysight (Agilent)
Keysight (Agilent) 6622A
20V 4A 50V 2A Dual Output System
2 Number of Outputs
0 to 20V (Channel 1), 0 to 20V (Channel 2) Output Voltage Range
0 to 2A (Channel 1), 0 to 2A (Channel 2) Output Current Range
40W per channel, 80W total Maximum Output Power
0.01% + 2mV Load Regulation (Voltage)
| Attribute | Value |
|---|---|
| Number of Outputs | 2 |
| Output Voltage Range | 0 to 20V (Channel 1), 0 to 20V (Channel 2) |
| Output Current Range | 0 to 2A (Channel 1), 0 to 2A (Channel 2) |
| Maximum Output Power | 40W per channel, 80W total |
| Load Regulation (Voltage) | 0.01% + 2mV |
| Load Regulation (Current) | 0.01% + 250µA |
| Programming Interface | GPIB (IEEE-488) |
| Output Isolation | ±240V from chassis ground |
| AC Input Voltage | 100/120/220/240 VAC, 47–63 Hz |
| Operating Temperature | 0°C to 55°C |
Keysight Technologies 6622A Options:
- 6622A - Opt 100 - 87 to 106 Vac, 47 to 66 Hz Input, 6.3 A (Japan only)
- 6622A - Opt 120 - 104 to 127 Vac, 47 to 63 Hz
- 6622A - Opt 220 - 191 to 233 Vac, 47 to 66 Hz, 3.0 A
- 6622A - Opt 240 - 209 to 250 Vac, 47 to 66 Hz, 3.0 A
- 6622A - Opt 750 - Relay Control and DFI/RI
- 6622A - Opt S50 - Similar to option 750, however the remote inhibit does not latch
- 6622A - Opt 908 - Rack-mount Kit (p/n 5062-3977)
- 6622A - Opt 909 - Rack-mount Kit w/Handles (p/n 5063-9221)
- 6622A - Opt 0L2 - Extra Standard Documentation Package
- 6622A - Opt 0B3 - Service Manual
- 6622A - Opt 0B0 - No documentation package
| Model | 6622A |
|---|
The Keysight (Agilent) 6622A is a dual-output DC power supply offering 0–20V/4A and 0–50V/2A ranges in a compact 3U chassis. It features programming accuracy of ±0.06% (+50 mV) for voltage and ±0.16% (+40 mA) for current, with low ripple at 500 µV RMS (voltage) and 1 mA RMS (current). Designed to reduce test time and improve measurement precision, it supports high-throughput automated test environments.
Its dual-range outputs and precise control capabilities make it ideal for multi-channel testing in development, production, and quality control labs.
Testwall can supply the used Keysight (Agilent) 6622A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) 6622A.
