Keysight (Agilent) 81133A
| Attribute | Value |
|---|---|
| Frequency Range | 15 MHz to 3.35 GHz |
| Number of Channels | 1 Channel |
| Output Voltage (High) | Up to 2.0 V into 50 Ω |
| Output Voltage (Low) | Down to -2.0 V into 50 Ω |
| Rise/Fall Time | < 150 ps (typical) |
| Timing Resolution | 1 ps |
| Pulse Width Range | 149 ps to 67 ns (frequency dependent) |
| Jitter (RMS) | < 3 ps RMS intrinsic jitter |
| Output Impedance | 50 Ω |
| Power Requirements | 100–240 V AC, 50/60 Hz, 150 VA maximum |
| Model | 81133A |
|---|
The Keysight (Agilent) 81133A is a high-performance simple pulse generator tailored for high-speed signal applications. It features fast rise times, low intrinsic jitter, and hardware-based PRBS and memory-based pattern generation, which enable accurate characterization of receivers, backplanes, and other sensitive devices. Its integrated graphical user interface simplifies parameter configuration and enhances testing efficiency, while clock and data signal distortion functionalities offer advanced signal emulation capabilities.
Ideal for precise testing environments, the 81133A supports high-speed transitions and advanced signal quality analysis. It offers rapid setup and control for demanding R&D or production workflows.
Testwall can supply the used Keysight (Agilent) 81133A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) 81133A.
