Keysight (Agilent) 8114A
| Attribute | Value |
|---|---|
| Channels | 1 |
| Pulse Width | 10 ns to 150 ms |
| Timing Resolution | 3 digits, 100 ps |
| Jitter | 0.03% ±25 ps RMS |
| Delay | 0 to 999 ms |
| Repetition Rate | 1 Hz to 15 MHz (66.7 ns to 999 ms) |
| Amplitude | 1 to 50 V or 20 mA to 1 A (50 Ω source), up to 100 V / 2 A (high Z source) |
| Transition Times | < 7 ns (50 Ω, > 5 V), < 12 ns (high Z source, > 10 V) |
| Output Impedance | 50 Ω or > 1 kΩ |
| Output Connector | BNC |
| Interfaces | GPIB |
| Dimensions | 426 × 133 × 422 mm |
| Weight | 14 kg |
Keysight Technologies 8114A Options:
- 8114A - 001 - Variable Baseline ± 25 V
- 8114A - UFJ - 1 MB Memory Card
- 8114A - UN2 - Rear Panel Connectors (instead of front panel)
- 8114A - 1CP - Rack Mount and Handle Kit (5063-9219)
- 8114A - 1CN - Handle Kit (5063-9226)
- 8114A - 1CM - Rack Mount Kit (5063-9212)
- 8114A - 1CR - Rack Slide Kit (1494-0059)
- 8114A - 0BW - Service Manual (08114-91021)
- 8114A - 0B2 - Additional English Language User's Guide (08114-91012)
The Keysight (Agilent) 8114A is a single-channel high power pulse generator offering fast, clean positive or negative pulses up to 100 V at frequencies up to 15 MHz. It features user-definable voltage, current, and duty cycle limits, with TTL input control for output enable/disable. It provides transitions of less than 12 ns into a 50 Ohm load, and < 7 ns in 50 Ohm/50 Ohm mode with a max voltage of 50 Vpp. Optional baseline shift of ±25 V supported.
Designed for modern telecom and computing systems, it supports components like laser diodes and EEPROMs requiring high voltage/current operations. It delivers up to 2 A max current in HI-Z/50 Ohm configuration.
Testwall can supply the used Keysight (Agilent) 8114A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) 8114A.
