Keysight (Agilent)
Keysight (Agilent) 8447E
Amplifier 0.1-1300MHz 22dB Gain
100 kHz to 1.3 GHz Frequency Range
25 dB (nominal) Gain
7 dB (nominal) Noise Figure
+10 dBm Maximum Input Power
+13 dBm (nominal) Output Power at 1 dB Compression
| Attribute | Value |
|---|---|
| Frequency Range | 100 kHz to 1.3 GHz |
| Gain | 25 dB (nominal) |
| Noise Figure | 7 dB (nominal) |
| Maximum Input Power | +10 dBm |
| Output Power at 1 dB Compression | +13 dBm (nominal) |
| Connector Type | BNC (female) |
| Power Supply Voltage | 15 VDC |
| Power Consumption | 500 mA maximum |
| Operating Temperature Range | 0°C to 55°C |
| Impedance | 50 Ohms |
Keysight Technologies 8447E Options:
- 8447E - 010 - N (f) connectors on single channel amplifier
- 8447E - 910 - Extra Operating and Service Manual (HP 8447D/E/F)
| Model | 8447E |
|---|
The Keysight (Agilent) 8447E RF Amplifier is a solid-state broadband amplifier operating from 100 kHz to 1.3 GHz, offering over 22 dB gain and a 3 dB bandwidth of 75 kHz to 1.4 GHz. Engineered for low noise, flat frequency response, and minimal distortion, it enhances signal strength and measurement accuracy across a broad range of RF applications. Its compact, lightweight design ensures easy integration into space-constrained setups without compromising performance.
This amplifier is ideal for RF environments requiring stable, low-distortion signal amplification.
Testwall can supply the used Keysight (Agilent) 8447E, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) 8447E.
