Keysight (Agilent) 8516A
| Attribute | Value |
|---|---|
| Frequency Range | 45 MHz to 40 GHz |
| Measurement Parameters | S-parameters (S11, S21, S12, S22) |
| Test Port Connector Type | 2.4 mm coaxial connectors |
| Dynamic Range | Up to 100 dB |
| Output Power Range | -85 dBm to +10 dBm |
| Impedance | 50 Ohms |
| Number of Test Ports | 2 |
| Compatible Instrument | Keysight 8510C Vector Network Analyzer |
| Interface | GPIB (IEEE-488) |
| Operating Temperature | 0°C to 55°C (32°F to 131°F) |
Keysight Technologies 8516A Options:
- 8516A - 001 - Add IF switching
- 8516A - 002 - Delete step attenuators and bias tees
- 8516A - 003 - High forward dynamic range
- 8516A - W30 - 2 years additional hardware service
| Model | 8516A |
|---|
The Keysight (Agilent) 8516A is a coupler-based test set featuring two alternative coupler configurations. Its standard symmetrical configuration delivers identical dynamic range for both forward (S21) and reverse (S12) transmission measurements. Integrated step attenuators on ports 1 and 2 allow precise power control for accurate testing.
Ideal for vector network analysis, this unit offers seamless power reduction flexibility during forward and reverse measurements, ensuring accurate and adaptable signal characterization.
Testwall can supply the used Keysight (Agilent) 8516A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) 8516A.
