Keysight (Agilent)
Keysight (Agilent) 86100A
Infiniium DCA Oscilloscope Mainframe
Up to 50 GHz (dependent on installed plug-in modules) Bandwidth
10 ps/div to 2 s/div Timebase Range
8 bits (12 bits in high-resolution mode) Vertical Resolution
Up to 40 GSa/s real-time equivalent time sampling Sampling Rate
Up to 4 channels (via dual plug-in module configuration) Number of Channels
| Attribute | Value |
|---|---|
| Bandwidth | Up to 50 GHz (dependent on installed plug-in modules) |
| Timebase Range | 10 ps/div to 2 s/div |
| Vertical Resolution | 8 bits (12 bits in high-resolution mode) |
| Sampling Rate | Up to 40 GSa/s real-time equivalent time sampling |
| Number of Channels | Up to 4 channels (via dual plug-in module configuration) |
| Display | 10.4-inch color TFT LCD display |
| Trigger Types | Edge, pattern, and clock recovery triggering |
| Input Impedance | 50 Ohms |
| Operating Temperature Range | 0°C to 45°C (32°F to 113°F) |
| Interface/Connectivity | GPIB, RS-232, and LAN (10Base-T Ethernet) |
| Model | 86100A |
|---|
The Keysight (Agilent) 86100A Infiniium DCA offers ultra-wide bandwidth oscilloscope capabilities exceeding 50 GHz, combining a digital communications analyzer and TDR for versatile high-speed signal analysis.
Supports eye diagram analysis, precise TDR/TDT for S-parameter measurements, and backward compatibility with 54750A and 83480A modules.
Testwall can supply the used Keysight (Agilent) 86100A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) 86100A.
