Keysight (Agilent) 86103B
| Attribute | Value |
|---|---|
| Optical Wavelength Range | 750 nm to 1650 nm |
| Electrical Bandwidth | DC to 20 GHz |
| Optical Bandwidth | 20 GHz |
| Input Connector Type | FC/PC optical connector |
| Trigger Input | SMA connector, 50 Ohm |
| Timebase Accuracy | ±1 ppm |
| Sensitivity (Optical) | -20 dBm average optical power minimum |
| Compatible Mainframes | Keysight 86100A/B/C/D Digital Communications Analyzer |
| Module Type | Dual-channel optical/electrical plug-in module |
| Operating Temperature Range | 0°C to 55°C |
Keysight Technologies 86103B Options:
- 86103B - 201 - 622 Mb/s, 2.488 Gb/s
- 86103B - 202 - 1.063, 1.25 Gb/s
- 86103B - 203 - 2.125, 2.488 Gb/s
| Model | 86103B |
|---|
The Keysight (Agilent) 86103B is an amplified optical and electrical module offering a 10 GHz optical bandwidth, high sensitivity, and compatibility with 86100A/B/C Infiniium DCA/DCA-J Mainframes. It operates across 1000–1600 nm wavelengths with support for 9/125 to 62.5/125 µm fibers and includes a 20 GHz electrical channel with 3.5 mm male input. Characteristic rms noise is 2.2 µW (10 GHz BW) for optical and 0.25 mV to 0.5 mV (12.4 to 20 GHz BW) for electrical channels.
Ideal for SONET/SDH, Fibre Channel, and Gigabit Ethernet compliance, the 86103B features reference receiver capabilities at 0.622 to 2.500 Gb/s rates, tailored for transceivers and proprietary interconnect testing.
Testwall can supply the used Keysight (Agilent) 86103B, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) 86103B.
