Keysight (Agilent) 87510A
| Attribute | Value |
|---|---|
| Frequency Range | 300 kHz to 1.3 GHz |
| Measurement Parameters | S-parameters (S11, S21, S12, S22), transmission and reflection |
| Dynamic Range | Up to 100 dB |
| Output Power Range | -60 dBm to 0 dBm |
| Impedance | 50 Ohms |
| Number of Ports | 2-port S-parameter test set |
| Connector Type | Type-N (female) |
| Compatible Analyzer | HP/Agilent/Keysight 8751A Network Analyzer |
| Directivity | Greater than 35 dB (typical) |
| Operating Temperature | 0°C to 55°C (32°F to 131°F) |
| Model | 87510A |
|---|
The Keysight (Agilent) 87510A Gain-Phase Analyzer operates from 100 kHz to 300 MHz, featuring a 1 MHz frequency resolution and output range from -45 dBm to +15 dBm. It includes an IF bandwidth of 8 kHz, 0.25 ms per point speed, and a 24-bit digital interface. Built for high-speed measurements, it supports HP Instrument BASIC, automatic parameter extraction, a built-in power splitter, and digital I/O.
Ideal for high-volume resonator and filter production, the HP 87510A ensures reliable gain and phase transmission testing with minimal delay and precise results.
Testwall can supply the used Keysight (Agilent) 87510A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) 87510A.
