Keysight (Agilent) 89611A
| Attribute | Value |
|---|---|
| Frequency Range | DC to 6 GHz |
| Analysis Bandwidth | Up to 36 MHz |
| Dynamic Range | Up to 90 dB |
| Displayed Average Noise Level (DANL) | -152 dBm/Hz (typical) |
| Input Impedance | 50 Ohm |
| Maximum Input Power | +30 dBm (1 Watt) |
| Amplitude Accuracy | ±0.5 dB (typical) |
| Software Platform | 89600 VSA Software |
| Digitizer Resolution | 14-bit ADC |
| Interface/Connectivity | LAN (LXI), USB, GPIB |
Keysight Technologies 89611A Options:
- 89611A - AYA - Vector modulation analysis
- 89611A - B7N - W-CDMA and cdma2000 modulation analysis (requires Option AYA, vector modulation analysis)
- 89611A - B7R - 802.11a OFDM and HiperLAN2 modulation analysis (requires Option AYA, vector modulation analysis)
- 89611A - 105 - Dynamic links to EEsof ADS
- 89611A - 144 - 144M byte time capture memory
- 89611A - 288 - 288M byte time capture memory
- 89611A - 001 - 1152M byte time capture memory
| Model | 89611A |
|---|
The Keysight (Agilent) 89611A is a vector signal analyzer that digitizes IF signals at 70 MHz, enabling deep analysis through its wide 36 MHz bandwidth, IF triggering, signal capture memory, and advanced DSP-based spectrum and modulation tools.
Ideal for evaluating GSM, CDMA, W-CDMA, 802.11, HiperLAN, and custom signals, the 89611A supports 24 digital demodulators, adaptive equalization, and precise time domain analysis using features like Time Gating and CCDF.
Testwall can supply the used Keysight (Agilent) 89611A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) 89611A.
