Keysight (Agilent) DSO7014A
| Attribute | Value |
|---|---|
| Bandwidth | 100 MHz |
| Number of Channels | 4 |
| Sample Rate | 2 GSa/s |
| Memory Depth | 8 Mpts (standard), up to 16 Mpts (optional) |
| Display | 12.1-inch XGA color display |
| Vertical Resolution | 8 bits |
| Vertical Sensitivity | 1 mV/div to 5 V/div |
| Time Base Range | 2 ns/div to 50 s/div |
| Trigger Types | Edge, Glitch, Pattern, CAN, LIN, I2C, SPI, USB (with optional licenses) |
| Connectivity / Interface | USB, LAN (LXI), GPIB (optional) |
Keysight (Agilent) DSO7014A Options:
- DSO7014A - N2741A - DSO to MSO upgrade for DSO701xA
- DSO7014A - SEC - Secure Environment Mode - Provides compliance with National Industrial Security Program Operating Manual (NISPOM) Chapter 8 requirements (factory-installed option only for new purchase)
- DSO7014A - A6J - ANSI Z540 compliant calibration
- DSO7014A - N5424A (AMS) - CAN/LIN automotive triggering and decode (4 and 4+16 channel models only)
- DSO7014A - N5423A (LSS) - I2C/SPI serial decode option (for 4/4+16 channel models only)
- DSO7014A - N5457A (232) - RS-232/UART triggering and decode (4 and 4+16 channel models only)
- DSO7014A - N5468A (SND) - I2S Triggering and Decode (4 and 4+16 channel models only)
- DSO7014A - N5432C (FLX) - FlexRay Measurements (4 and 4+16 channel models only)
- DSO7014A - N5469A (553) - MIL-STD 1553 Triggering and Decode (4 and 4+16 channel models only)
- DSO7014A - N5454A (SGM) - Segmented memory
- DSO7014A - N5455A (LMT) - Mask limit testing
- DSO7014A - B4610A - Offline viewing and analysis of MSO/DSO data on a PC
- DSO7014A - U1881A - Power measurement and analysis application
- DSO7014A - E2690B - ASA's Oscilloscope tools
| Model | DSO7014A |
|---|
El osciloscopio Keysight (Agilent) DSO7012B cuenta con 100 MHz de ancho de banda, muestreo de 2 GSa/s y 2 canales analógicos con memoria de 8 Mpts. Su pantalla XGA de 12,1″ con 256 niveles de intensidad ofrece detalles nítidos en un chasis compacto (16,5 cm de profundidad, 6 kg), silencioso.
Disfruta de la tasa de actualización líder de 100.000 formas de onda/s, memoria segmentada, prueba de máscara y análisis offline en PC para capturar eventos raros y sutiles.
Testwall puede suministrar el Keysight (Agilent) DSO7012B usado, totalmente probado. Con soporte experto y entrega global, Testwall garantiza instrumentación de alto rendimiento con fiabilidad y calidad de servicio inigualables. Contáctanos si necesitas calibración o reparación del Keysight (Agilent) DSO7012B.
