Keysight (Agilent) DSOX3032A
| Attribute | Value |
|---|---|
| Number of Channels | 2 |
| Bandwidth | 300 MHz |
| Sample Rate | 2 GSa/s |
| Memory Depth | 2 Mpts standard (4 Mpts with MegaZoom IV technology) |
| Display | 8.5-inch WVGA (800 x 480) color display |
| Vertical Resolution | 8-bit (up to 12-bit with high resolution mode) |
| Vertical Sensitivity | 1 mV/div to 10 V/div |
| Time Base Range | 2 ns/div to 50 s/div |
| Waveform Update Rate | 1,000,000 waveforms per second |
| Connectivity | USB, LAN (LXI), and optional GPIB |
Keysight (Agilent) DSOX3032A Options:
- DSOX3032A - DSOX3MEMUP - Memory upgrade (standard 2 Mpts to 4 Mpts)
- DSOX3032A - DSOX3SGM - Segmented memory
- DSOX3032A - DSOX3MSO - MSO upgrade: add 16 digital timing channels (for 500 MHz and below models)
- DSOX3032A - DSOX3WAVEGEN - WaveGen built-in 20 MHz function/arbitrary waveform generator
- DSOXDVM - DSOXDVM - Integrated 3-digit digital voltmeter (DVM)
- DSOX3032A - DSOX3EMBD - Embedded serial triggering and analysis (I2C, SPI)
- DSOX3032A - DSOX3COMP - Computer serial triggering and analysis (RS232/422/485/UART)
- DSOX3032A - DSOX3AUTO - Automotive serial triggering and analysis (CAN, LIN)
- DSOX3032A - DSOX3FLEX - FlexRay serial triggering and analysis
- DSOX3032A - DSOX3AUDIO - Audio serial triggering and analysis (I2S)
- DSOX3032A - DSOX3AERO - Aerospace serial triggering and analysis (MIL-STD 1553, ARINC 429)
- DSOX3032A - DSOX3PWR - Power measurements and analysis application
- DSOX3032A - DSOX3MASK - Mask/limit testing
- DSOX3032A - DSOX3VID - Enhanced video/TV triggering and analysis (HDTV)
- DSOX3032A - DSOX3ADVMATH - Advanced waveform math
- DSOX3032A - DSOXEDK - Educator's oscilloscope training kit
- DSOX3032A - DSOX3BW24 - Bandwidth upgrade: 100 MHz to 200 MHz, 4 ch, License only
- DSOX3032A - DSOX3BW52 - Bandwidth upgrade: 350 MHz to 500 MHz, 2 ch, License only
- DSOX3032A - DSOX3BW54 - Bandwidth upgrade: 350 MHz to 500 MHz, 4 ch, License only
- DSOX3032A - DSOX3BW32 - Bandwidth upgrade: 100 MHz to 350 MHz, 2 ch, Service center
- DSOX3032A - DSOX3BW34 - Bandwidth upgrade: 200 MHz to 350 MHz, 4 ch, Service center
- DSOX3032A - DSOX3BW12 - Bandwidth upgrade: 500 MHz to 1 GHz, 2 ch, Service center
- DSOX3032A - DSOX3BW14 - Bandwidth upgrade: 500 MHz to 1 GHz, 4 ch, Service center
- DSOX3032A - DSOXLAN - LAN/VGA connection module
- DSOX3032A - DSOXGPIB - GPIB connection module
| Model | DSOX3032A |
|---|
The Keysight (Agilent) DSOX3032A Oscilloscope is a 2-channel device from the InfiniiVision 3000 X-Series, offering 350 MHz bandwidth and up to 4 GSa/s sampling. It integrates five instruments in one: oscilloscope, digital channels, waveform generator, voltmeter, and protocol analyzer, with a high update rate of over one million waveforms per second and an 8.5-inch WVGA display.
With its MegaZoom IV smart memory, upgradeable bandwidth to 1 GHz, and flexible trigger and acquisition systems, it's ideal for complex waveform analysis and embedded system debugging.
Testwall can supply the used Keysight (Agilent) DSOX3032A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) DSOX3032A.
