Keysight (Agilent) E4862A
| Attribute | Value |
|---|---|
| Frequency Range | 100 kHz to 2 MHz |
| Measurement Parameters | C-D, C-R, C-G, Z-θ, L-D, L-R, L-Q, R-X, G-B, Y-θ |
| Basic Accuracy | 0.1% |
| Test Signal Level (Voltage) | 5 mV to 1 V RMS |
| Test Signal Level (Current) | 50 µA to 10 mA RMS |
| DC Bias Voltage | 0 to ±2 V (internal), 0 to ±40 V (external) |
| Impedance Range | 1 mΩ to 100 MΩ |
| Interface | GPIB, USB, LAN |
| Display | 6.5-inch color LCD |
| Number of Test Frequencies | Up to 201 points per sweep |
Keysight (Agilent) E4862A Options:
- E4805B - Opt 002 - 8 line trigger input for TTL signals (useful when branching on external events (hardware signals) other than VXI-ECL trigger lines or compare errors)
- E4805B - Opt 003 - De-skew probe (Comprises Agilent 1144A 880MHz active probe and a BNC (f) to SMA (m) adapter (part number 1250-1200))
- E4849C - 013 - IEEE 1394 PC link to VXI (1 slot) controller option to control the system from an external PC
- E4849C - 002 - VXI extender module (E1482B) so that one or two expander frames (E4848B) can be connected, for a total of 31 data modules
- E4860A - 152 - Expansion frame
- E4860AS - 014 - External PC preinstalled with Windows NT and 81200 SW
- E4839A - - Test Fixture
- Agilent - 15443A - Cable Kit SMA (m) to SMA (m), matched pair
- Agilent - 15442A - Cable Kit: 4*SMA(m) to SMA(m) 1 meter
- Agilent - 15441A - Cable Kit: 10*SMA(m) to SCI Connector
- Agilent - 8120-4948 - SMA coax. cable, 1 m.
- Agilent - 8710-1582 - Torque wrench, SMA.
- Agilent - 15440A - Adapter Kit: 4* SMA(m) I/O Adapter
- Agilent - 1250-1200 - Adapter SMA (m)/BNC (f).
- Agilent - 1250-1249 - Adapter right-angle SMA (m-f).
- Agilent - 1250-1397 - Adapter right-angle SMA (m-m).
- Agilent - 1250-1698 - Adapter tee SMA.
- Agilent - 11667B - Pulse adder/splitter, SMA.
- Agilent - 15433B - 500 ps transition converter.
- Agilent - 15434B - 1 ns transition converter.
- Agilent - 15438B - 2 ns transition converter.
- Agilent - 10833B - Cable, GPIB.
| Model | E4862A |
|---|
The Keysight (Agilent) E4862A Analyzer operates in a data rate range from 333 Mb/s to 2.7 Gb/s, supporting both differential and single-ended I/Os. It generates and analyzes pseudo random word sequences (PRWS) and PRBS up to 231-1, with memory-based patterns up to 64 Mb. The generator offers amplitude of 0.5 to 1.8V pp and typical transition time of 90ps, while jitter performance is <50ps in data mode and <5ps RMS in clock mode. The analyzer module features 50 ohm impedance, 50mV input sensitivity, and accepts up to -2V to +3V input range.
Designed for performance monitoring and component testing, the E4862A is ideal for sectors including medical, automotive, and engineering. It precisely measures signals, voltages, and frequencies.
Testwall can supply the used Keysight (Agilent) E4862A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) E4862A.
