Keysight (Agilent) E4864A
| Attribute | Value |
|---|---|
| Product Family | Medalist i3070 In-Circuit Test System |
| Module Type | Digital Pin Card / Functional Test Module |
| Compatibility | Keysight Medalist i3070 Series 5 In-Circuit Test Platform |
| Number of Pins | 64 digital pins per card |
| Maximum Operating Voltage | 5.5 V |
| Drive Current | Up to 32 mA per pin |
| Measurement Function | In-circuit and functional board testing |
| Interface | Compatible with i3070 test head backplane interface |
| Operating Temperature | 0°C to 55°C (32°F to 131°F) |
| Form Factor | Plug-in module card for i3070 mainframe chassis |
| Model | E4864A |
|---|
The Keysight (Agilent) E4864A enhances mid-speed ParBERT systems by transforming them into precise pattern generators for SERDES, digital-video, and GigE device testing. It features a differential output delivering low-jitter data streams up to 1.33 Gb/s with programmable voltage swing and edge speed. The unit includes built-in PRBS/PRWS pattern memory and an on-card delay line supporting ±500 ps jitter insertion for accurate signal testing.
Supporting bit rates from 333 Mb/s to 1.33 Gb/s with 1 Hz steps, the E4864A includes a 50 Ω differential output, wide voltage swing, sharp edge transitions, and compact single-slot design to optimize chassis use.
Testwall can supply the used Keysight (Agilent) E4864A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) E4864A.
