Keysight (Agilent)
Keysight (Agilent) E5280A
High Power Source / Monitor Unit.
±100 V (High Voltage Mode), ±20 V (Medium Voltage Mode) Voltage Output Range
±1 A (High Current Mode), ±100 mA (Low Current Mode) Current Output Range
0.5 µV (minimum resolution in high-resolution mode) Voltage Measurement Resolution
10 fA (minimum resolution in high-resolution mode) Current Measurement Resolution
1 channel per module (designed for use in B5500A/B mainframe) Number of Channels
| Attribute | Value |
|---|---|
| Voltage Output Range | ±100 V (High Voltage Mode), ±20 V (Medium Voltage Mode) |
| Current Output Range | ±1 A (High Current Mode), ±100 mA (Low Current Mode) |
| Voltage Measurement Resolution | 0.5 µV (minimum resolution in high-resolution mode) |
| Current Measurement Resolution | 10 fA (minimum resolution in high-resolution mode) |
| Number of Channels | 1 channel per module (designed for use in B5500A/B mainframe) |
| Output Power | Maximum 20 W per channel |
| Measurement Functions | Voltage and current sourcing and measurement (SMU functionality) |
| Interface/Compatibility | Compatible with Keysight B1500A Semiconductor Device Analyzer mainframe |
| Source Monitor Unit (SMU) Type | High Power Source/Monitor Unit (HPSMU) |
| Operating Temperature Range | 5°C to 40°C (41°F to 104°F) |
| Model | E5280A |
|---|
The Keysight (Agilent) E5280A High Power Source/Measurement Unit (HPSMU) integrates with the E5270A 8-slot Parametric Measurement Mainframe, offering precise voltage and current control with a range of 2 µV to 200 V and 10 fA to 1 A.
This dual-slot module is fully user-configurable, supporting flexible module installation options for advanced parametric testing in semiconductor characterization and device modeling.
Testwall can supply the used Keysight (Agilent) E5280A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) E5280A.
