Keysight (Agilent) E8364B
| Attribute | Value |
|---|---|
| Frequency Range | 10 MHz to 50 GHz |
| Number of Ports | 2-Port |
| Dynamic Range | Up to 118 dB |
| Output Power Range | -85 dBm to +10 dBm |
| Trace Noise (10 Hz IF Bandwidth) | 0.004 dB RMS |
| Connector Type | 2.4 mm (female) |
| IF Bandwidth Range | 1 Hz to 40 kHz |
| Number of Data Points per Sweep | 1 to 16,001 |
| Measurement Parameters | S-parameters (S11, S21, S12, S22), impedance, admittance, group delay |
| Power Supply | 100–240 VAC, 50/60 Hz |
Keysight (Agilent) E8364B Options:
Options available for the Keysight (Agilent) PNA series microwave network analyzers (E8361/E8362/E8363/E8364). Installed options vary from unit to unit – ask us for the exact configuration of the instrument you are interested in.
- E8364B - 010 - Time-domain measurements
- E8364B - 014 - Configurable test set (front-panel access loops)
- E8364B - UNL - Extended power range and bias-tees
- E8364B - 016 - Receiver attenuators
- E8364B - 080 - Frequency-offset mode
- E8364B - 081 - Reference receiver switch
- E8364B - 082 - Scalar-calibrated converter measurements
- E8364B - 083 - Frequency converter application with vector-calibrated measurements
- E8364B - H08 - Pulsed-RF measurement capability
- E8364B - H11 - IF access
- E8364B - 1CM - Rack mount kit
- E8364B - 1CP - Rack mount kit with handles
The Keysight (Agilent) E8364B is a high-performance network analyzer offering 104 dB dynamic range and <0.006 dB trace noise. It features up to 32 channels and 16,001 points, with a rapid measurement speed of <26 μs/point. Advanced capabilities include TRM/LRM calibration for precise on-wafer and waveguide analysis, and support for mixer conversion loss and amplifier gain compression testing.
Ideal for RF applications, the E8364B supports multiport, pulsed-RF testing, harmonic, IMD, and group delay evaluations. Extensive customization is available through optional software and hardware configurations.
Testwall can supply the used Keysight (Agilent) E8364B, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) E8364B.
