Keysight (Agilent)
Keysight (Agilent) MSOX6002A
1 GHz, 2 Analog Channels, 16 Digital Channels
1 GHz Bandwidth
2 Number of Analog Channels
16 Number of Digital Channels
5 GSa/s Maximum Sample Rate
4 Mpts standard (up to 1 Gpts with option) Memory Depth
| Attribute | Value |
|---|---|
| Bandwidth | 1 GHz |
| Number of Analog Channels | 2 |
| Number of Digital Channels | 16 |
| Maximum Sample Rate | 5 GSa/s |
| Memory Depth | 4 Mpts standard (up to 1 Gpts with option) |
| Display | 12.1-inch capacitive touch screen display, 1280 x 800 resolution |
| Waveform Update Rate | Up to 1,000,000 waveforms per second |
| Vertical Resolution | 8-bit (up to 16-bit with high resolution mode) |
| Serial Protocol Triggering and Analysis | Supports I2C, SPI, UART, CAN, LIN, and more (with optional licenses) |
| Connectivity | USB, LAN (LXI Core), GPIB (optional), USB Device Port for remote programming |
Keysight (Agilent) MSOX6002A Options:
- MSOX6002A - DSOX6B10T252BW - 1.0 to 2.5 GHz bandwidth upgrade, 2 ch, fixed perpetual license
- MSOX6002A - DSOX6B10T402BW - 1.0 to 4.0 GHz bandwidth upgrade, 2 ch, fixed perpetual license
- MSOX6002A - DSOX6B10T602BW - 1.0 to 6.0 GHz bandwidth upgrade, 2 ch, fixed perpetual license
- MSOX6002A - DSOX6B25T402BW - 2.5 to 4.0 GHz bandwidth upgrade, 2 ch, fixed perpetual license
- MSOX6002A - DSOX6B25T602BW - 2.5 to 6.0 GHz bandwidth upgrade, 2 ch, fixed perpetual license
- MSOX6002A - DSOX6B40T602BW - 4.0 to 6.0 GHz bandwidth upgrade, 2 ch, fixed perpetual license
- MSOX6002A - DSOX6APPBNDL - Software application bundle (includes all software applications)
- MSOX6002A - DSOX6AERO - MIL-STD 1553 and ARINC 429 serial triggering and analysis
- MSOX6002A - DSOX6AUDIO - Audio serial triggering and analysis (I2S)
- MSOX6002A - DSOX6AUTO - Automotive serial triggering and analysis (CAN, CAN-dbc, CAN-FD, LIN)
- MSOX6002A - DSOX6COMP - Computer serial triggering and analysis (RS232/UART)
- MSOX6002A - DSOX6EMBD - Embedded serial triggering and analysis (I2C, SPI)
- MSOX6002A - DSOX6FLEX - FlexRay serial triggering and analysis
- MSOX6002A - DSOX6SENSOR - SENT (Single Edge Nibble Transmission) triggering and analysis
- MSOX6002A - DSOX6USBFL - USB 2.0 Full/Low Speed serial decode and triggering
- MSOX6002A - DSOX6USBH - USB 2.0 Hi-Speed serial decode and triggering
- MSOX6002A - DSOXDVMCTR - Integrated digital voltmeter and 10 digit counter
- MSOX6002A - DSOX6FPGAX - FPGA dynamic probe option for Xilinx
- MSOX6002A - DSOX6JITTER - Jitter and real time eye diagram analysis
- MSOX6002A - DSOX6MASK - Mask limit testing
- MSOX6002A - DSOX6PWR - Power analysis application
- MSOX6002A - DSOX6USBSQ - USB 2.0 signal quality test
- MSOX6002A - DSOX6VID - Enhanced video/TV application package
- MSOX6002A - DSOX6WAVEGEN2 - Dual channel WaveGen 20 MHz AWG
- MSOX6002A - DSOX6MSO - InfiniiVision 6000 X-Series oscilloscope MSO upgrade
- MSOX6002A - DSOXEDK - Education and training kit
- MSOX6002A - N8900A - Infiniium offline oscilloscope analysis software
- MSOX6002A - BV0000A - BenchVue software
| Model | MSOX6002A |
|---|
The Keysight (Agilent) MSOX6002A is a high-performance mixed-signal oscilloscope offering 2 GHz analog bandwidth and 20 GSa/s sample rate, supporting 2 analog and 16 digital channels for comprehensive signal analysis.
It features a 12.1-inch capacitive touch display, real-time waveform math, serial decoding, multi-window mode, and advanced logic tools to enhance high-speed embedded system debugging.
Testwall can supply the used Keysight (Agilent) MSOX6002A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) MSOX6002A.
