Keysight (Agilent) N1092D
| Attribute | Value |
|---|---|
| Number of Ports | 4 |
| Wavelength Range | 1260 nm to 1640 nm |
| Dynamic Range | Up to 70 dB |
| Measurement Speed | Up to 1000 nm/s |
| Optical Return Loss Measurement | Yes, integrated ORL measurement capability |
| Optical Sampling Resolution | 0.1 pm |
| Display Points | Up to 200,001 data points per trace |
| Connectivity | LAN, USB, GPIB |
| Operating Temperature Range | 0°C to 55°C |
| Power Supply | 100–240 V AC, 50/60 Hz |
Keysight (Agilent) N1092D Options:
- N1092D - 30A - 30 GHz amplified
- N1092D - 40A - > 40 GHz amplified (includes an unfiltered path and 53 GBd PAM4 TDECQ filter)
- N1092D - 280 - 25.781, 27.739, 27.952, 28.050 Gbaud filters (mandatory)
- N1092D - LOJ - Low jitter timebase
- N1092D - STB - Standard timebase
- N1092D - PLK - Pattern lock capability
- N1092D - FS1 - Fast sampling rate
- N1092D - 200 - Enhanced jitter analysis software, fixed perpetual license
- N1092D - 201 - Advanced waveform analysis software, fixed perpetual license
- N1092D - 300 - Advanced amplitude analysis/Rin/Q-Factor, fixed perpetual license
- N1092D - 401 - Advanced eye analysis software, fixed perpetual license
- N1092D - 500 - Productivity package, fixed perpetual license
- N1092D - 9FP - PAM-N analysis SW, fixed perpetual license
- N1092D - TFP - IEEE TDECQ analysis, fixed perpetual license
- N1092D - PLK - Pattern lock trigger hardware
- N1092D - IRC - Impulse response correction
- N1092D - EFP - FlexEye Independent Channel Acquisition and Control
- N1092D - SIM - InfiniiSim-DCA waveform transformation SW, fixed perpetual license
- N1092D - 168 - Additional 25.78 Gb/s TDEC filter (requires Option 500)
- N1092D - 206 - Additional 20.625 Gb/s filter
- N1092D - C0C - Certificate of Calibration
- N1092D - UK6 - Commercial calibration certificate with test data
- N1092D - 1CM - Single instrument rack mount kit
- N1092D - 1CN - Dual instrument side-by-side rack mount kit
| Model | N1092D |
|---|
The Keysight (Agilent) N1092D offers a high-accuracy, low-cost optical waveform analysis solution with support for baud rates from 8.4 to 64 GBaud. It delivers precise high-speed signal characterization with <5 µW noise, <200 fs jitter, and >40 GHz bandwidth (option 40A). The compact unit enables fast testing with 250 kHz sampling and includes USB and power cables.
Ideal for engineers needing high-throughput and sensitivity in optical signal evaluation, the N1092D integrates seamlessly with DCA-X mainframes or user PCs.
Testwall can supply the used Keysight (Agilent) N1092D, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) N1092D.
