Keysight (Agilent) N4446A
| Attribute | Value |
|---|---|
| Frequency Range | 10 MHz to 26.5 GHz |
| Number of Ports | 4-port |
| Connector Type | 3.5 mm (f) |
| Dynamic Range | Up to 123 dB |
| Measurement Speed | 3 µs per point (fast sweep mode) |
| Output Power Range | -85 dBm to +10 dBm |
| Trace Noise | Less than 0.004 dB RMS |
| Compatible Platform | PNA-X Series Network Analyzer (N5242A) |
| Application | S-parameter measurements, amplifier characterization, and noise figure analysis |
| Power Requirements | 100-240 VAC, 50/60 Hz |
| Model | N4446A |
|---|
The Keysight (Agilent) N4446A is a balanced measurement system optimized for differential component and circuit analysis across 50 MHz to 20 GHz. It enables accurate S-parameter measurements critical for high-speed digital and RF systems, with support for balanced and mixed-mode operation.
Featuring compatibility with Agilent 8720ES network analyzers, it includes a source attenuator for precision signal control and allows for time-domain analysis, extending test versatility.
Testwall can supply the used Keysight (Agilent) N4446A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) N4446A.
