Keysight (Agilent) N6785A
| Attribute | Value |
|---|---|
| Output Voltage Range | 0 to 20 V |
| Output Current Range | -3 A to +3 A (Source and Sink) |
| Power Rating | 20 W |
| Measurement Functions | Voltage, Current, and Power Measurement with Data Logging |
| Current Measurement Ranges | 1 mA, 10 mA, 100 mA, 1 A, 3 A |
| Digitizer Sample Rate | Up to 200,000 samples per second (200 kSa/s) |
| Form Factor | Single-Wide Module for Keysight N6700 Series Mainframe |
| Interface/Connectivity | GPIB, USB, and LAN (via N6700 Mainframe) |
| Operating Temperature | 0°C to 55°C |
| Compliance Standards | CE, CSA, UL, IEC 61010-1 |
| Model | N6785A |
|---|
The Keysight (Agilent) N6785A Source/Measure Unit delivers up to 80W of power with voltage ranges from 6V to 20V and current up to ±8A. Featuring seamless measurement ranging and 18-bit digitizers, it ensures precise monitoring from nA to A. Its programmable output resistance and auxiliary DVM enhance dynamic battery drain analysis and emulation.
Ideal for portable device testing, the N6785A captures all operating modes—off, sleep, standby, transmit—in a single view without range switching. Works well with Keysight 14585A software for extended insights.
Testwall can supply the used Keysight (Agilent) N6785A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) N6785A.
