Keysight (Agilent) U2356A
| Attribute | Value |
|---|---|
| Number of Channels | 16 single-ended / 8 differential analog input channels |
| Sampling Rate | 250 kSa/s aggregate sampling rate |
| Resolution | 16-bit analog-to-digital converter (ADC) |
| Input Voltage Range | ±10 V, ±5 V, ±2.5 V, ±1.25 V (software selectable) |
| Analog Output Channels | 2 analog output channels, 16-bit resolution |
| Digital I/O Lines | 24 digital I/O lines (TTL compatible) |
| Bus Interface | USB 2.0 High-Speed interface |
| Counter/Timer | 2 counter/timer channels, 32-bit |
| Operating Temperature | 0 °C to 55 °C |
| Power Supply | USB bus-powered, no external power supply required |
Keysight (Agilent) U2356A Options:
- U2356A - U2802A - 31-Channel Thermocouple Input Device
- U2356A - U2901A - Terminal block and SCSI-II 68-pin connector with 1-meter cable
- U2356A - U2902A - Terminal block and SCSI-II 68-pin connector with 2-meter cable
| Model | U2356A |
|---|
The Keysight (Agilent) U2356A is a high-speed USB 2.0 data acquisition module with 16-bit resolution and up to 500 kSa/s sampling rate. It offers 64 SE/32 DI analog input channels, 2 12-bit analog output channels, 24-bit TTL I/O channels, and 2 digital counters. BenchVue software (BV0025B) included for automation.
Ideal for standalone or modular use, the U2356A enables physical measurement, closed-loop control, and waveform output. Compatible with LabVIEW, MATLAB, VEE, and Visual Studio.
Testwall can supply the used Keysight (Agilent) U2356A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) U2356A.
