LeCroy SDA 5000A
20GSa/s 5GHz Serial Data Analyser
5 GHz Bandwidth
20 GS/s (single channel), 10 GS/s (dual channel) Sample Rate
4 Number of Channels
up to 48 Mpts/Ch (with memory options) Memory Depth
8 bits Vertical Resolution
| Attribute | Value |
|---|---|
| Bandwidth | 5 GHz |
| Sample Rate | 20 GS/s (single channel), 10 GS/s (dual channel) |
| Number of Channels | 4 |
| Memory Depth | up to 48 Mpts/Ch (with memory options) |
| Vertical Resolution | 8 bits |
| Rise Time | 70 ps |
| Input Impedance | 50 Ω / 1 MΩ |
| Display | 10.4-inch color LCD touchscreen |
| Serial Data Analysis | Integrated SDA (Serial Data Analyzer) with jitter, eye diagram, and bathtub curve analysis |
| Connectivity / Interface | USB, Ethernet (LAN), GPIB (optional), Windows-based operating system |
| Model | SDA 5000 |
|---|
The LeCroy SDA 5000A is a 5 GHz serial data analyzer featuring real-time capture capabilities combined with advanced signal integrity tools for in-depth analysis. It includes jitter and eye diagram measurements, with memory scalability for extended acquisitions.
This unit offers ~5 GHz analog bandwidth, advanced jitter/eye analysis, and signal integrity diagnostics, making it ideal for high-speed digital signal evaluation.
Testwall can supply the used LeCroy SDA 5000A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the LeCroy SDA 5000A.
