Tektronix TPA-N-PRE
| Attribute | Value |
|---|---|
| Compatibility | Tektronix TDS/TPS/DPO/MSO Series Oscilloscopes |
| Probe Type | Preamplifier Adapter for N2782A Current Probe |
| Bandwidth | DC to 100 MHz |
| Input Connector | BNC |
| Output Connector | TekProbe Interface |
| Power Supply | Powered via TekProbe Interface from oscilloscope |
| Function | Provides preamplification and interface conversion for compatible current probes |
| Probe Interface Standard | TekProbe Level II |
| Operating Temperature | 0°C to +50°C |
| Storage Temperature | -40°C to +71°C |
Tektronix TPA-N-PRE Options:
- TPA-N-PRE - C3 - Calibration Service 3 years (initial certification, plus 2 calibrations)
- TPA-N-PRE - C5 - Calibration Service 5 years (initial certification, plus 4 calibrations)
- TPA-N-PRE - R3 - Repair Service. Repair warranty extended to cover 3 years
- TPA-N-PRE - R5 - Repair Service. Repair warranty extended to cover 3 years
- TPA-N-PRE - R3DW - Repair Service Coverage 3 Years (includes product warranty period). 3-year period starts at time of customer instrument purchase
- TPA-N-PRE - R5DW - Repair Service Coverage 5 Years (includes product warranty period). 5-year period starts at time of customer instrument purchase
| Model | TPA-N-PRE |
|---|
The Tektronix TPA-BNC is a precision preamplifier module offering a wide frequency range from 9 kHz to 6 GHz and a nominal gain of 12 dB. It significantly enhances signal clarity by providing a 10 dB DANL improvement, ideal for capturing low-power signals with high fidelity. This preamp is tailored for integration with MDO4000 and MDO3000 Series Mixed Domain Oscilloscopes, ensuring optimal performance in noise-sensitive applications.
Designed for precise measurements, it excels in identifying weak signals in complex environments, especially in R&D and diagnostic applications requiring high sensitivity.
Testwall can supply the used Tektronix TPA-BNC, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix TPA-BNC.
