LeCroy WaveMaster 8600A XXL
4 Channel 20GSa/s 6GHz Digital Oscilloscope
6 GHz Bandwidth
20 GS/s (single channel), 10 GS/s (all channels) Sample Rate
4 Number of Channels
up to 256 Mpts/Ch (XXL memory option) Record Length
8-bit (up to 11-bit with enhanced resolution) Vertical Resolution
| Attribute | Value |
|---|---|
| Bandwidth | 6 GHz |
| Sample Rate | 20 GS/s (single channel), 10 GS/s (all channels) |
| Number of Channels | 4 |
| Record Length | up to 256 Mpts/Ch (XXL memory option) |
| Vertical Resolution | 8-bit (up to 11-bit with enhanced resolution) |
| Input Impedance | 50 Ω / 1 MΩ |
| Display | 15.3-inch color LCD touchscreen |
| Timebase Range | 20 ps/div to 800 s/div |
| Trigger Types | Edge, Width, Glitch, Pattern, TV, Serial Protocol, and more |
| Connectivity / Interfaces | USB, Ethernet (LAN), GPIB (optional), VGA output |
| Model | WaveMaster 8600A |
|---|
The LeCroy WaveMaster 8600A XXL offers a full 6 GHz real-time analog bandwidth and supports 40–80 GS/s high-speed sampling, making it ideal for detailed waveform capture and analysis.
With XXL memory for extended signal recording and an X-Stream-like fast analysis pipeline, it ensures precise debugging with long-duration waveform capability and accurate serial data analysis.
Testwall can supply the used LeCroy WaveMaster 8600A XXL, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the LeCroy WaveMaster 8600A XXL
