Marconi IFR Aeroflex 1600S
| Attribute | Value |
|---|---|
| Frequency Range | 0.4 MHz to 1000 MHz |
| RF Output Level Range | -137 dBm to +13 dBm |
| Modulation Types | AM, FM, Phase Modulation, Pulse Modulation |
| FM Deviation Range | Up to 400 kHz |
| AM Depth Range | 0% to 99.9% |
| Internal Modulation Frequency | 20 Hz to 100 kHz |
| Frequency Resolution | 1 Hz |
| Output Impedance | 50 Ohms |
| Power Supply | 90 to 265 VAC, 48 to 440 Hz |
| Interface/Connectivity | GPIB (IEEE-488) Remote Control Interface |
Marconi IFR Aeroflex 1600S Options:
- 1600S - 1600S - FM/AM-1600S Service Monitor
- 1600S - 1600S-C - FM/AM-1600S Service Monitor with Certificate of Calibration
- 1600S - CSA4 - CSA4 (IS-54, GPIB, UWC-136, TDMA, 400 & 800 MHz)
- 1600S - CSA4-C - CSA4 (IS-54, GPIB, UWC-136, TDMA, 400 & 800 MHz) with Certificate of Calibration
- 1600S - 1600SNAMPS - FM/AM-1600S/CSA, NAMPS
- 1600S - 1600SCSA4 - CSA4 System (includes 1600S Service Monitor CSA4 with IS-54, GPIB, UWC-136, TDMA, 400 & 800 MHz) with Certificate of Calibration
- 1600S - 1600SCSA4-C - CSA4 Systems (includes 1600S Service Monitor and CSA4 with IS-54, GPIB, UWC-136, TDMA, 400 & 800 MHz) with Certificate of Calibration
- 1600S - AC0300 - TMAC User Manual
- 1600S - AC510 - Paging Encoder
- 1600S - AC1009 - EasySpan for DOS (Waveform Transfer Software)
- 1600S - AC1009W - EasySpan for Windows (Transfer Software)
- 1600S - AC1010 - Easy-Com-FM (Land Mobile Test Software)
- 1600S - AC1011 - EasyScan (Spectral Usage Software) (req. AC9157)
- 1600S - AC1012 - AutoCell-882 (Ericsson 882 Test Software) (req. AC9157)
- 1600S - AC1017 - AutoCell Series II (Lucent Series II Test) (req. AC9157)
- 1600S - AC1018 - AutoCell-Motorola (Motorola LD & HD Test) (req. 1600SNAMPS and AC9157)
- 1600S - AC1019 - EasySweep (Swept Antenna Measurements) (req. AC9157)
- 1600S - AC1020D - AutoCell-NTD (NT/Novatel/GE/NTTRU) (req. AC9157)
- 1600S - AC1021 - CellScan Cellular Bar Graph RF Level Meter (req. AC9157)
- 1600S - AC1036 - UWC-136 Conformance Software (req. CSA4)
- 1600S - AC1048 - SSD Update & Authentication Test (req. CSA4)
- 1600S - AC1201 - Telescopic Antenna
- 1600S - AC4101 - Return Loss Bridge (5 MHz to 1 GHz)
- 1600S - AC4102 - Return Loss Bridge Kit (5 MHz to 1 GHz) (includes AC1019)
- 1600S - AC4103 - Return Loss Bridge Kit (5 MHz to 2 GHz) (includes AC1019)
- 1600S - AC8600 - Maintenance Manual
- 1600S - AC8645 - Microphone
- 1600S - AC9153 - Carrying Case
- 1600S - AC9154 - NT400 System Test (req. CSA4)
- 1600S - AC9155 - AMPS Cellular System Analyzer
- 1600S - AC9156 - AMPS Mobile Station Test
- 1600S - AC9157 - 2.5 MB File System
- 1600S - AC9158 - Rubidium Time Base
| Model | 1600S |
|---|
The Marconi‑IFR‑Aeroflex 1600s RF generator is engineered for precision and reliability, delivering low‑distortion, clean signals with highly stable, repeatable output. Wide frequency support accommodates diverse test plans, while excellent spectral purity supports accurate measurements. Rugged construction and tight internal regulation minimize drift over time and temperature, ensuring consistent performance in laboratory and field environments for telecom infrastructure, devices, and research setups.
For telecom and R&D workflows, it simplifies stimulus generation for receivers, modulators, filters, and subsystems, maintaining dependable operation during long runs, regressions, and qualification test sequences.
Testwall can supply the used Marconi‑IFR‑Aeroflex 1600s, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Marconi‑IFR‑Aeroflex 1600s.
