Ophir 5086
| Attribute | Value |
|---|---|
| Wavelength Range | 0.15 – 12 µm |
| Power Range | 10 mW – 300 W |
| Energy Range | 1 mJ – 300 J |
| Detector Type | Thermopile |
| Aperture | 30 mm |
| Sensitivity | 5 V/W |
| Maximum Average Power Density | 5 kW/cm² |
| Response Time (1/e) | 1.5 sec |
| Connector Type | DB-15 |
| Operating Temperature | 15 – 40 °C |
Ophir 5086 Options:
- 5086 - RE - R model w/Control Option
- 5086 - FE - F model w/Control Option
- 5086 - RT - RE model w/Ethernet Interface
- 5086 - FT - FE model w/Ethernet Interface
| Model | 5086 |
|---|
The Ophir 5086 is a broadband RF amplifier delivering 200 Watts of output power across 0.01 to 200 MHz. Operating in Class AB, it ensures a high 3rd order intercept point, superior gain of +50 dB minimum, and excellent flatness within ±1.5 dB. With a 50-ohm impedance, input VSWR of 2:1, and internal forced-air cooling, it provides reliability even under demanding RF environments.
This amplifier achieves 125 Watts CW minimum at 1 dB compression, supports 100–240 VAC input, and integrates temperature protection with automatic shutdown above 80°C. Housed in a compact 19-inch rackmount case, it operates from 0°C to 50°C with 95% non-condensing humidity tolerance.
Testwall can supply the used Ophir 5086, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Ophir 5086.
