Pacific Power 345LSX
| Attribute | Value |
|---|---|
| Output Voltage Range | 0 to 300 VAC (single phase), programmable in 0.1V increments |
| Frequency Range | 45 Hz to 500 Hz, programmable in 0.1 Hz increments |
| Power Output | 3 kVA continuous output power |
| Output Phases | Single phase and split phase output configurations |
| Total Harmonic Distortion (THD) | Less than 0.5% THD at full resistive load |
| Input Voltage | 208 VAC, three-phase, 50/60 Hz |
| Output Current | Up to 10 A RMS continuous per phase |
| Regulation | ±0.1% voltage regulation from no load to full load |
| Control Interface | Front panel display with programmable memory settings and IEEE-488/RS-232 remote interface |
| Protection Features | Overcurrent, overtemperature, and output short-circuit protection with automatic shutdown |
Pacific Power 345LSX Options:
- 345LSX - T - Transformer Option (Direct/Transformer Coupled Selectable Output, 45 Hz - 1200 Hz)
- 345LSX - C - Interharmonics Generator Option
- 345LSX - E - Export Version
- 345LSX - LSXM - Reduced Feature Set Economy Version (sine wave only, no transient programming, no harmonic measurements, no waveform capture, no programmable output impedance)
| Model | 345LSX |
|---|
The Pacific Power Source 345LSX delivers low output voltage noise, minimal distortion, and exceptional AC waveform fidelity. Designed with a powerful micro-controller, it functions as a fully integrated test system supporting simple frequency conversion, harmonic testing, and programmable transient simulation. It provides two or three-phase output with quartz-crystal stabilized frequency control from 15 to 5,000 Hz, ensuring highly stable AC voltage delivery.
With precise control, the 345LSX efficiently converts single-phase input into split-phase or three-phase output. It supports output voltages up to 135VL-N in single-phase, 270VL-L in split-phase, and up to 585VL-L in three-phase configurations, making it versatile for diverse power testing applications.
Testwall can supply the used Pacific Power Source 345LSX, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Pacific Power Source 345LSX.
