Philips PM5696G
| Attribute | Value |
|---|---|
| Signal Type | TV Test Signal Generator |
| Output Standards | PAL, NTSC, SECAM |
| Video Output | Composite and Component Video Signals |
| Frequency Range | VHF/UHF Band Coverage |
| Modulation | AM/FM Modulation Supported |
| RF Output Level | Adjustable RF Output Level |
| Test Patterns | Multiple Standard Test Patterns Including Color Bars, Crosshatch, and Gray Scale |
| Audio Output | Built-in Audio Signal Generation with Standard Tone Frequencies |
| Power Supply | 100–240V AC, 50/60 Hz Universal Input |
| Connector Types | BNC and Standard RF (75 Ohm) Connectors |
| Model | PM5696G |
|---|
The Philips PM5696G generates advanced TV test signals with enhanced graphical patterns, offering excellent color fidelity and precise alignment. Its flexible adjustments and multi-standard compatibility make it ideal for R&D and servicing tasks, ensuring reliable performance across professional applications.
This unit is especially suited for television manufacturers and service departments, where signal integrity and color accuracy are essential. Its rugged design ensures durability during long-term professional use.
Testwall can supply the used Philips PM5696G, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Philips PM5696G.
