keysight (agilent) N5241B

PNA-X Microwave Network Analyzer, 13.5 GHz

Model: keysight (agilent) N5241B
Description: PNA-X Microwave Network Analyzer, 13.5 GHz
Data Sheet PDF: keysight (agilent) N5241B

The PNA-X is an integrated vector network analyzer featuringa built-in S-parameter test set, one or two synthesized sourcesused for device stimulus, a solid-state drive, USB interfaces,and a 12.1” LCD touch screen display. The N5241B, N5242B, andN5249B have 50 ohm, ruggedized 3.5 mm (m) test ports. TheN5244B and the N5245B have 50 ohm, ruggedized 2.4 mm (m)test ports. The N5247B has 50 ohm, ruggedized 1.85 mm (m) testports. Included with each instrument is a mouse, keyboard (, a 3-year return-to-Keysight service warranty, and one dayof on-site productivity assistance (PS-S20-PNA).

Key Features and Functions

  • Simplify your test stations by replacing racks and stacks of equipment
  • Increase productivity with the most integrated and flexible single-connection microwave test engine
  • Reduce test time with the world’s widest range of single-connection measurement applications
  • Accurately test linear and nonlinear device characterization using advanced error correction
  • Accelerate insight into component behavior using a multi-touch display and intuitive user interface

keysight (agilent) N5241B Product Overview
