Quadtech 1867
| Attribute | Value |
|---|---|
| Measurement Function | Inductance (L), Capacitance (C), Resistance (R), Impedance (Z), Dissipation Factor (D), Quality Factor (Q), Phase Angle (θ) |
| Test Frequency Range | 20 Hz to 1 MHz |
| Basic Accuracy | 0.05% |
| Test Signal Level (Voltage) | 5 mV to 1.275 V RMS |
| DC Bias Voltage | 0 to 2 V internal; up to 40 V external |
| Display | Dual 6-digit LCD display with backlight |
| Interface / Connectivity | IEEE-488 (GPIB) and RS-232 standard interfaces |
| Measurement Speed | Fast, Medium, and Slow measurement modes available |
| Equivalent Circuit Modes | Series and Parallel measurement modes selectable |
| Power Requirements | 90–250 V AC, 47–63 Hz, 30 VA maximum |
Quadtech 1867 Options:
- 1867 - 1865-01 - IEEE Interface Option
- 1867 - 1865-02 - Data/Extended Program Storage Option
- 1867 - 1865-03 - Rear Panel Input Option
- 1867 - S16 - Rack Mount Kit
| Model | 1867 |
|---|
The QuadTech 1867 Megohmmeter delivers precise insulation resistance testing with programmable voltages up to 2000V. Its wide measurement range extends to teraohms, ensuring suitability for diverse materials and components. Engineered for speed and accuracy, it is ideal for compliance and quality assurance testing in demanding environments.
Featuring fast response cycles and advanced safety mechanisms, the QuadTech 1867 enhances productivity while protecting users. Its intuitive interface and data output capabilities simplify integration into automated systems, making it a versatile tool.
Testwall can supply the used QuadTech 1867, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the QuadTech 1867.
